All In-stock Isolators

At DiTom, we offer a wide selection of high-quality RF isolators to meet your needs. All of our isolators listed below are in-stock and can be ordered directly from our website.

Click on the model number link below to customize and order your hardware. All connector and port configurations are available.

Contact DiTom and we’ll be happy to customize a product to your exact specifications.

Single junction Isolators

Dual junction Isolators

Frequency (GHz)Model NumberIsolation (dB)Insertion Loss (dB)VSWR 1-24 25-99 100+ Availability
0.40 - 0.50D3I0405160.61.40:1$1,195.00 $1,140.00 $1,085.00 In-Stock!
0.50 - 0.55D3I0555200.41.25:1$795.00 $760.00 $725.00 In-Stock!
0.50 - 0.55D4I0555400.81.25:1$1,600.00 $1,520.00 $1,445.00 1-2 Weeks
0.50 - 0.70D3I0507160.71.35:1$895.00 $855.00 $815.00 In-Stock!
0.50 - 1.00D3I0501141.01.50:1$3,495.00 $3,325.00 $3,160.00 In-Stock!
0.525 - 0.60D3I0560200.41.25:1$795.00 $760.00 $725.00 In-Stock!
0.525 - 0.60D4I0560400.81.25:1$1,600.00 $1,520.00 $1,445.00 1-2 Weeks
0.60 - 0.70D3I0670200.41.25:1$795.00 $760.00 $725.00 In-Stock!
0.60 - 0.70D4I0670400.81.25:1$1,600.00 $1,520.00 $1,445.00 1-2 Weeks
0.698 - 0.80D3I0780N200.41.25:1$695.00 $665.00 $635.00 In-Stock!
0.698 - 0.80D3I0780S200.41.25:1$695.00 $665.00 $635.00 In-Stock!
0.698 - 0.80D4I0780400.81.25:1$1,400.00 $1,330.00 $1,265.00 1-2 Weeks
0.698 - 1.00D3I0710N160.61.40:1$795.00 $760.00 $725.00 In-Stock!
0.698 - 1.00D3I0710S160.61.40:1$795.00 $760.00 $725.00 In-Stock!
0.80 - 0.90D3I0890200.41.25:1$450.00 $430.00 $410.00 In-Stock!
0.80 - 0.90D4I0890400.81.25:1$900.00 $855.00 $815.00 1-2 Weeks
0.80 - 1.00D3I0810N200.41.25:1$495.00 $475.00 $455.00 In-Stock!
0.80 - 1.00D3I0810S200.41.25:1$495.00 $475.00 $455.00 In-Stock!
0.80 - 1.00D4I0810N400.81.25:1$1,000.00 $950.00 $905.00 1-2 Weeks
0.80 - 1.00D4I0810S400.81.25:1$1,000.00 $950.00 $905.00 1-2 Weeks
0.80 - 2.00D3I0802N141.01.50:1$1,100.00 $1,045.00 $995.00 In-Stock!
0.80 - 2.00D3I0802S141.01.50:1$1,100.00 $1,045.00 $995.00 In-Stock!
0.95 - 1.23D3I9525N200.41.25:1$595.00 $570.00 $545.00 In-Stock!
0.95 - 1.23D3I9525S200.41.25:1$595.00 $570.00 $545.00 In-Stock!
0.95 - 1.23D4I9525400.81.25:1$1,200.00 $1,140.00 $1,085.00 1-2 Weeks
0.95 - 1.70D3I9517N180.51.30:1$795.00 $760.00 $725.00 In-Stock!
0.95 - 1.70D3I9517S180.51.30:1$795.00 $760.00 $725.00 In-Stock!
0.95 - 2.15D3I9521N121.01.65:1$1,050.00 $1,000.00 $950.00 In-Stock!
0.95 - 2.15D3I9521S121.01.65:1$1,050.00 $1,000.00 $950.00 In-Stock!
1.00 - 2.00D3I0102N180.51.30:1$795.00 $760.00 $725.00 In-Stock!
1.00 - 2.00D3I0102S180.51.30:1$795.00 $760.00 $725.00 In-Stock!
1.20 - 1.40D3I0112200.41.25:1$450.00 $430.00 $410.00 In-Stock!
1.20 - 1.40D4I0112400.81.25:1$900.00 $855.00 $815.00 1-2 Weeks
1.40 - 1.60D3I0116200.41.25:1$450.00 $430.00 $410.00 In-Stock!
1.40 - 1.60D4I0116400.81.25:1$900.00 $855.00 $815.00 1-2 Weeks
1.50 - 2.50D3I1525160.61.40:1$895.00 $855.00 $815.00 In-Stock!
1.50 - 3.00D3I1530160.71.40:1$995.00 $950.00 $905.00 In-Stock!
1.60 - 1.80D3I0118200.41.25:1$450.00 $430.00 $410.00 In-Stock!
1.60 - 1.80D4I0118400.81.25:1$900.00 $855.00 $815.00 1-2 Weeks
1.70 - 2.00D3I0120200.41.25:1$450.00 $430.00 $410.00 In-Stock!
1.70 - 2.00D3I1720N200.41.25:1$450.00 $430.00 $410.00 In-Stock!
1.70 - 2.00D3I1720S200.41.25:1$450.00 $430.00 $410.00 In-Stock!
1.70 - 2.00D4I0120400.81.25:1$900.00 $855.00 $815.00 1-2 Weeks
1.70 - 2.00D4I1720N400.81.25:1$900.00 $855.00 $815.00 1-2 Weeks
1.70 - 2.00D4I1720S400.81.25:1$900.00 $855.00 $815.00 1-2 Weeks
1.70 - 2.20D3I1722N200.41.25:1$495.00 $475.00 $455.00 In-Stock!
1.70 - 2.20D3I1722S200.41.25:1$495.00 $475.00 $455.00 In-Stock!
1.70 - 2.20D4I1722N400.81.25:1$1,000.00 $950.00 $905.00 1-2 Weeks
1.70 - 2.20D4I1722S400.81.25:1$1,000.00 $950.00 $905.00 1-2 Weeks
1.70 - 2.50D3I1725170.61.35:1$495.00 $475.00 $455.00 In-Stock!
1.70 - 2.70D3I1727200.51.30:1$795.00 $760.00 $725.00 In-Stock!
2.00 - 2.30D3I0223200.41.25:1$450.00 $430.00 $410.00 In-Stock!
2.00 - 2.30D4I0223400.81.25:1$900.00 $855.00 $815.00 1-2 Weeks
2.00 - 4.00D3I2040180.51.30:1$450.00 $430.00 $410.00 In-Stock!
2.00 - 4.00D4I2040361.01.30:1$900.00 $855.00 $815.00 1-2 Weeks
2.00 - 6.00D3I2060140.81.50:1$895.00 $855.00 $815.00 In-Stock!
2.00 - 6.00D4I2060281.61.50:1$1,800.00 $1,710.00 $1,625.00 1-2 Weeks
2.00 - 8.00D3I208091.752.1:1$995.00 $950.00 $905.00 In-Stock!
2.30 - 2.70D3I2327N200.41.25:1$495.00 $475.00 $455.00 In-Stock!
2.30 - 2.70D3I2327S200.41.25:1$495.00 $475.00 $455.00 In-Stock!
2.30 - 2.70D4I2327400.81.25:1$1,000.00 $950.00 $905.00 1-2 Weeks
2.60 - 5.20D3I2652180.61.30:1$450.00 $430.00 $410.00 In-Stock!
2.60 - 5.20D4I2652361.01.30:1$900.00 $855.00 $815.00 1-2 Weeks
2.60 - 5.30DMI2652151.01.50:1$595.00 $570.00 $545.00 In-Stock!
3.00 - 6.00D3I3060180.51.30:1$450.00 $430.00 $410.00 In-Stock!
3.00 - 6.00D4I3060361.01.30:1$900.00 $855.00 $815.00 1-2 Weeks
3.00 - 9.00D3I3090141.01.50:1$795.00 $760.00 $725.00 In-Stock!
3.40 - 4.20D3I3442200.41.25:1$450.00 $430.00 $410.00 In-Stock!
3.50 - 7.00D3I3570170.51.35:1$450.00 $430.00 $410.00 In-Stock!
3.50 - 7.00D4I3570341.01.35:1$900.00 $855.00 $815.00 1-2 Weeks
3.70 - 4.20D3I3742230.31.15:1$450.00 $430.00 $410.00 In-Stock!
3.70 - 4.20D4I3742460.61.15:1$900.00 $855.00 $815.00 1-2 Weeks
3.70 - 8.30D3I3783170.61.35:1$450.00 $430.00 $410.00 In-Stock!
3.70 - 8.30D4I3783341.21.35:1$900.00 $855.00 $815.00 1-2 Weeks
4.00 - 12.00D3I4012141.01.50:1$895.00 $855.00 $815.00 In-Stock!
4.00 - 8.00D3I4080200.41.25:1$450.00 $430.00 $410.00 In-Stock!
4.00 - 8.00D4I4080400.81.25:1$900.00 $855.00 $815.00 1-2 Weeks
4.40 - 5.00D3I4450230.31.15:1$450.00 $430.00 $410.00 In-Stock!
4.40 - 5.00D4I4450460.61.15:1$900.00 $855.00 $815.00 1-2 Weeks
5.00 - 10.70DMI5011151.01.45:1$595.00 $570.00 $545.00 In-Stock!
5.00 - 15.00D3I5015141.01.50:1$695.00 $665.00 $635.00 In-Stock!
5.40 - 5.90D3I5459230.31.15:1$450.00 $430.00 $410.00 In-Stock!
5.40 - 5.90D4I5459460.61.15:1$900.00 $855.00 $815.00 1-2 Weeks
5.70 - 7.10D3I5771180.51.30:1$450.00 $430.00 $410.00 In-Stock!
5.80 - 14.50D3I5814150.81.30:1$595.00 $570.00 $545.00 In-Stock!
5.90 - 6.40D3I5964230.31.15:1$450.00 $430.00 $410.00 In-Stock!
5.90 - 6.40D4I5964460.61.15:1$900.00 $855.00 $815.00 1-2 Weeks
6.00 - 12.40D3I6012170.61.35:1$450.00 $430.00 $410.00 In-Stock!
6.00 - 12.40D4I6012341.21.35:1$900.00 $855.00 $815.00 1-2 Weeks
6.00 - 18.00DMI6018141.01.50:1$1,050.00 $1,000.00 $950.00 In-Stock!
7.00 - 11.00D3I7011200.51.25:1$450.00 $430.00 $410.00 In-Stock!
7.00 - 11.00D4I7011401.01.25:1$900.00 $855.00 $815.00 1-2 Weeks
7.00 - 12.40D3I7012180.51.30:1$450.00 $430.00 $410.00 In-Stock!
7.00 - 12.40D4I7012361.01.30:1$900.00 $855.00 $815.00 1-2 Weeks
7.00 - 18.00D3I7018151.01.50:1$650.00 $620.00 $590.00 In-Stock!
7.00 - 18.00D4I7018342.01.50:1$1,300.00 $1,235.00 $1,175.00 1-2 Weeks
7.50 - 10.00D3I7510200.51.25:1$450.00 $430.00 $410.00 In-Stock!
7.50 - 10.00D4I7510401.01.25:1$900.00 $855.00 $815.00 1-2 Weeks
7.70 - 8.40D3I7784230.31.20:1$450.00 $430.00 $410.00 In-Stock!
7.70 - 8.40D4I7784460.61.20:1$900.00 $855.00 $815.00 1-2 Weeks
8.00 - 12.40D3I8012200.51.25:1$450.00 $430.00 $410.00 In-Stock!
8.00 - 12.40D4I8012401.01.25:1$900.00 $855.00 $815.00 1-2 Weeks
8.00 - 16.00D3I8016170.61.35:1$450.00 $430.00 $410.00 In-Stock!
8.00 - 16.00D4I8016341.21.35:1$900.00 $855.00 $815.00 1-2 Weeks
8.00 - 18.00D3I8018160.81.45:1$495.00 $475.00 $455.00 In-Stock!
8.00 - 18.00D4I8018321.61.45:1$1,000.00 $950.00 $905.00 1-2 Weeks
8.00 - 20.00D3I8020151.01.45:1$575.00 $550.00 $525.00 In-Stock!
8.00 - 20.00D4I8020302.01.45:1$1,150.00 $1,095.00 $1,045.00 1-2 Weeks
8.50 - 9.60D3I8596230.31.20:1$450.00 $430.00 $410.00 In-Stock!
8.50 - 9.60D4I8596460.61.20:1$900.00 $855.00 $815.00 1-2 Weeks
9.20 - 10.50D3I9211230.31.20:1$450.00 $430.00 $410.00 In-Stock!
9.20 - 10.50D4I9211460.61.20:1$900.00 $855.00 $815.00 1-2 Weeks
10.00 - 20.00D3I1020160.71.40:1$495.00 $475.00 $455.00 In-Stock!
10.00 - 20.00D4I1020321.41.40:1$1,000.00 $950.00 $905.00 1-2 Weeks
10.70 - 11.70D3I1112230.31.20:1$450.00 $430.00 $410.00 In-Stock!
10.70 - 11.70D4I1112460.61.20:1$900.00 $855.00 $815.00 1-2 Weeks
10.70 - 12.75D3I1012230.31.20:1$450.00 $430.00 $410.00 In-Stock!
10.70 - 14.80D3I1014230.31.20:1$495.00 $475.00 $455.00 In-Stock!
11.70 - 12.70D3I1213230.31.20:1$450.00 $430.00 $410.00 In-Stock!
11.70 - 12.70D4I1213460.61.20:1$900.00 $855.00 $815.00 1-2 Weeks
12.00 - 18.00D3I1218200.51.25:1$450.00 $430.00 $410.00 In-Stock!
12.00 - 18.00D4I1218401.01.25:1$900.00 $855.00 $815.00 1-2 Weeks
12.75 - 14.50D3I1214230.31.20:1$450.00 $430.00 $410.00 In-Stock!
14.00 - 15.00D3I1415230.31.20:1$450.00 $430.00 $410.00 In-Stock!
14.00 - 15.00D4I1415460.61.20:1$900.00 $855.00 $815.00 1-2 Weeks
16.00 - 19.00D3I1619200.51.25:1$495.00 $475.00 $455.00 In-Stock!
17.00 - 20.00D3I1720220.41.20:1$495.00 $475.00 $455.00 In-Stock!
17.00 - 20.00D4I1720440.81.20:1$1,000.00 $950.00 $905.00 1-2 Weeks
17.30 - 22.00D3I1822200.51.25:1$495.00 $475.00 $455.00 In-Stock!
18.00 - 26.50D3I1826180.81.40:1$600.00 $570.00 $545.00 In-Stock!
18.00 - 26.50D3I1826K180.81.40:1$675.00 $645.00 $615.00 In-Stock!
18.00 - 26.50D4I1826361.61.40:1$1,200.00 $1,140.00 $1,085.00 1-2 Weeks
18.00 - 26.50D4I1826K361.61.40:1$1,350.00 $1,285.00 $1,225.00 1-2 Weeks
18.00 - 40.00D3I184092.12.10:1$1,400.00 $1,330.00 $1,265.00 In-Stock!
18.00 - 40.00D4I1840184.22.10:1$2,800.00 $2,660.00 $2,530.00 1-2 Weeks
19.00 - 22.00D3I1922220.41.20:1$495.00 $475.00 $455.00 In-Stock!
19.00 - 22.00D4I1922440.81.20:1$1,000.00 $950.00 $905.00 1-2 Weeks
20.00 - 21.50D3I2021220.41.20:1$495.00 $475.00 $455.00 In-Stock!
20.00 - 21.50D4I2021440.81.20:1$1,000.00 $950.00 $905.00 1-2 Weeks
20.00 - 23.00D3I2023220.41.20:1$495.00 $475.00 $455.00 In-Stock!
20.00 - 23.00D4I2023440.81.20:1$1,000.00 $950.00 $905.00 1-2 Weeks
20.00 - 30.00D3I2030160.71.40:1$1,050.00 $1,000.00 $950.00 In-Stock!
20.00 - 30.00D4I2030321.41.40:1$2,100.00 $1,995.00 $1,900.00 1-2 Weeks
20.00 - 40.00D3I2004102.02.00:1$1,300.00 $1,235.00 $1,175.00 In-Stock!
20.00 - 40.00D4I2004204.02.00:1$2,600.00 $2,470.00 $2,350.00 1-2 Weeks
24.00 - 28.00D3I2428200.51.25:1$850.00 $810.00 $770.00 In-Stock!
26.50 - 40.00D3I2640141.01.50:1$1,050.00 $1,000.00 $950.00 In-Stock!
26.50 - 40.00D3I2640Q141.01.50:1$1,350.00 $1,285.00 $1,225.00 In-Stock!
26.50 - 40.00D4I2640282.01.50:1$2,100.00 $1,995.00 $1,900.00 1-2 Weeks
27.00 - 31.00D3I2731200.61.25:1$850.00 $810.00 $770.00 In-Stock!
27.00 - 31.00D3I2731Q200.61.25:1$1,150.00 $1,095.00 $1,045.00 In-Stock!
31.00 - 33.00D3I3133200.61.25:1$850.00 $810.00 $770.00 In-Stock!
33.00 - 37.00D3I3337180.71.25:1$950.00 $905.00 $860.00 In-Stock!
37.00 - 40.00D3I3740180.71.35:1$950.00 $905.00 $860.00 In-Stock!
37.00 - 40.00D3I3740Q180.71.25:1$1,250.00 $1,190.00 $1,135.00 In-Stock!
37.00 - 43.00D3I3743141.21.35:1$1,250.00 $1,190.00 $1,135.00 In-Stock!
37.00 - 43.00D3I3743Q141.21.35:1$1,550.00 $1,475.00 $1,405.00 In-Stock!
38.00 - 41.00D3I3841171.01.30:1$1,150.00 $1,095.00 $1,045.00 In-Stock!
38.00 - 41.00D3I3841Q171.01.30:1$1,450.00 $1,380.00 $1,315.00 In-Stock!
40.00 - 42.00D3I4042200.81.25:1$1,150.00 $1,095.00 $1,045.00 In-Stock!
40.00 - 42.00D3I4042Q200.81.25:1$1,450.00 $1,380.00 $1,315.00 In-Stock!
40.00 - 43.50D3I4043181.21.50:1$1,150.00 $1,095.00 $1,045.00 In-Stock!
40.00 - 43.50D3I4043Q181.21.50:1$1,450.00 $1,380.00 $1,315.00 In-Stock!
