High Reliability Military Isolators and Circulators
All models below are suitable for Hi-Reliability Military applications. They can be ordered directly from our website.
Models can have customized bandwidths, finishes, and testing requirements to satisfy ground based, naval, or aerospace end users.
Contact DiTom and we’ll be happy to customize a product for your specifications.
Military Isolators
- All DHIxxxx part numbers below
Military Circulators
- All DHCxxxx part numbers below
| Frequency (GHz) | Model Number | Isolation (dB) | Insertion Loss (dB) | VSWR | 1-24 | 25-99 | 100+ | Availability |
|---|---|---|---|---|---|---|---|---|
| 2.00 - 6.00 | DHI2060 | 14 | 1.0 | 1.50:1 | $1,400.00 | $1,330.00 | $1,260.00 | 3-4 Weeks |
| 2.00 - 6.00 | DHC2060 | 14 | 1.0 | 1.50:1 | $1,400.00 | $1,330.00 | $1,260.00 | 3-4 Weeks |
| 6.00 - 18.00 | DHI6018 | 14 | 0.8 | 1.50:1 | $1,550.00 | $1,473.00 | $1,395.00 | 3-4 Weeks |
| 6.00 - 18.00 | DHC6018 | 14 | 0.8 | 1.50:1 | $1,550.00 | $1,473.00 | $1,395.00 | 3-4 Weeks |
| 8.00 - 12.40 | DHI8012 | 20 | 0.5 | 1.25:1 | $950.00 | $903.00 | $855.00 | 3-4 Weeks |
| 8.00 - 12.40 | DHC8012 | 20 | 0.5 | 1.25:1 | $950.00 | $903.00 | $855.00 | 3-4 Weeks |
| 17.30 - 22.00 | DHI1722 | 20 | 0.5 | 1.25:1 | $1,000.00 | $950.00 | $900.00 | 3-4 Weeks |
| 17.30 - 22.00 | DHC1722 | 20 | 0.5 | 1.25:1 | $1,000.00 | $950.00 | $900.00 | 3-4 Weeks |
